Brinde que faz a máquina
Created with Pixso. Turnkey Industrial Sandwich Bread Line Featuring Whole Grain Flake Topping System

Turnkey Industrial Sandwich Bread Line Featuring Whole Grain Flake Topping System

Marca: Zline (Industrial Dough Solution)
Número do modelo: Personalizado (com base na capacidade)
Quantidade mínima: 1 conjunto (teste de produção de suporte)
Preço: Get Latest Project Quote
Prazo de entrega: Agendado por escala de projeto (30-45 dias)
Condições de pagamento: T/T,L/C
Informações pormenorizadas
Lugar de origem:
China
Certificação:
CE
Adaptabilidade da Massa:
Centeio, Trigo Integral, Multigrãos, Fermento (35%-80%+ Hidratação)
Capacidade de produção:
500 - 2.500 kg/h (com base nas especificações do produto)
Principais tecnologias:
Folhas sem estresse, laminação de linha dupla, semeadura de flocos, despanagem a vácuo
Gama de assadeiras:
Assadeiras e formas de pão com várias alças (personalizáveis)
Nível de automação:
Linha turnkey totalmente automatizada (da alimentação ao ensacamento)
Sistema de controle:
PLC central, servo drive multieixo, tela sensível ao toque HMI
Materiais e Higiene:
Correias de PU aprovadas pela FDA em aço inoxidável SUS304 de qualidade alimentar, laváveis ​​IP65
linha disposição:
Design modular (layout personalizado linear, em forma de L ou em U)
Detalhes da embalagem:
Caixa de madeira reforçada para equipamentos industriais pesados
Habilidade da fonte:
Capacidade de Fornecimento de Projetos Personalizados
Descrição do produto

Fully Automated Whole Grain & Rye Pan Bread Production Line


This high-capacity, turnkey loaf bread production line delivers a seamless, fully automated process from raw dough feeding to the final sealed package. Engineered with advanced stress-free sheeting and sanitary post-bake handling, this line is the ultimate solution for commercial bakeries producing premium rye, whole wheat, and seeded toast loaves.


                            Industrial pan bread makeup line layout drawing showcasing automated dough sheeters, double-line laminating swing arms, and automatic flake topping system for commercial loaf production.


Dough Feeding & Gentle Sheeting


  • Dough Bowl Lifter & Tilter: The process begins with a heavy-duty bowl elevator that lifts and tilts the mixing bowl, gently discharging the fermented grain dough into the hopper of the dough band former (sheeter).

  • Stress-Free Multi-Roller Sheeting: To protect the delicate gluten structure of whole wheat and rye dough, a series of multi-roller satellite sheeters and calibrating rollers gradually reduce the dough band to the target thickness. This gentle reduction ensures the crumb texture of the finished pan bread remains soft and airy.

  • Longitudinal Slitting: On the forming table, a set of high-precision stationary slitting cutter cleanly cuts the wide, continuous dough band into parallel, uniform dough strips.

     Industrial dough bowl lifter elevating and discharging fermented rye dough into the former hopper.         verlapping dough sheets connecting seamlessly to form a continuous dough band on the conveyor.
     Three consecutive multi-roller calibrating sheeters reducing the whole grain dough band to a glossy and uniform thickness.          Stationary slitting knives dividing the continuous whole wheat dough band into multiple parallel strips.



Seeding, Rolling & Panning


  • Moulding & Rolling: The parallel dough strips pass through specialized mesh rollers (moulding belts), which tightly roll the flat dough into uniform cylindrical dough logs.

  • Automated Topping & Seeding: An integrated dry ingredient topper/seeding machine precisely spreads rolled whole wheat flakes, grains, and seed blends onto the rolled dough logs, enhancing the rustic appearance and texture.

  • Servo Guillotine Cutting & Aligning: An aligning device gathers the seeded dough logs into tight rows before they reach the servo guillotine cutter, which cleanly snips the dough into uniform, standard-length loaf dough pieces.

  • Automated Panning System: A high-speed panning depositor accurately drops the dough portions directly into the multi-strap pan bread baking moulds positioned on the conveyor.


      High-speed moulding rollers on the forming table rolling divided dough strips into tight bread logs.        Dough log aligning guides gathering the rolled strips before passing under the automatic whole grain flake and seed topper.
      High-precision servo guillotine cutter cleanly dividing the seeded dough logs into uniform bread portions.        Automated panning depositor accurately dropping cut bread portions into baking strap pans.

Proving, Baking & Depanning


  • Proving & Baking: The loaded loaf pans travel through the final prover (proofing chamber) to develop the ideal volume, followed by baking in the tunnel oven. The bread emerges with a signature golden-brown crust and rustic artisan texture.

  • Robotic Vacuum Depanner: Immediately after baking, an automated vacuum depanner (suction cup depanning system) lifts the golden-brown toast loaves out of the hot baking moulds with minimal contact, preventing damage to the delicate crust.

    Plump and smooth whole grain dough loaves proven and expanded inside the baking moulds before entering the oven.       Robotic vacuum depanner with suction cups gently lifting golden-brown baked bread loaves out of hot baking pans.


Cooling, Slicing & Packaging


  • Spiral Cooling Tower System: The depanned hot bread is transferred onto a continuous spiral cooling conveyor for ambient cooling, ensuring the internal crumb temperature stabilizes before slicing.

  • High-Speed Bread Slicer: Once cooled, the whole grain loaves pass through a high-speed reciprocating band slicer to achieve precise, uniform slice thickness with minimal crumb loss.

  • Automated Bagging & Sealing: The sliced toast loaves are automatically pushed into pre-made bags by a pneumatic bread bagger and secured with a twist-tie or clip closure, ready for warehouse distribution.

    Automated spiral cooling conveyor system lowering internal crumb temperature of freshly baked rye loaves.       Automated bread bagging machine pushing sliced loaves into pre-made bags with automatic or manual sealing options.
